DB25SBT - Socket, D, T&D, 25Way, Pk5

Socket, D, T&D, 25Way, Pk5; No. Of Contacts:25Contacts; Gender:Receptacle; Contact Termination Type:Solder; D Sub Shell Size:Db; Product Range:Standard D Series; Connector Body Material:Steel Body; Contact Material:Copper Alloy; Contact Plating:Gold Plated Contacts; Svhc:No Svhc (17-Dec-2015); Body Plating:Tin; Case Material:Steel, Tin Plating; Connector Mounting:Through Hole Mount; Contact Resistance:10Mohm; Contact Termination:Solder; Current Temperature:70°C; D Sub Connector Type:Standard; Dc Current Max:6.5A; Flammability Rating:Ul94v-0; Insulation Resistance:100Mohm; Material:Steel; No. Of Mating Cycles:300; Operating Temperature Max:105°C; Operating Temperature Min:-55°C; Termination Method:Tinned; Working Voltage:500V
