IXFN200N10P - Mosfet, N, Sot-227B

Mosfet, N, Sot-227B; Transistor Polarity:N Channel; Continuous Drain Current Id:200A; Drain Source Voltage Vds:100V; On Resistance Rds(On):0.0075Ohm; Rds(On) Test Voltage Vgs:15V; Threshold Voltage Vgs:5V; Power Dissipation Pd:680W; Transistor Case Style:Isotop; No. Of Pins:4Pins; Operating Temperature Max:175°C; Product Range:Polar(Tm) Hiperfet; Automotive Qualification Standard:-; Msl:-; Svhc:No Svhc (12-Jan-2017); Capacitance Ciss Typ:7600Pf; Current Id Max:200A; Junction To Case Thermal Resistance A:0.22°C/W; N-Channel Gate Charge:235Nc; Operating Temperature Min:-55°C; Operating Temperature Range:-55°C To +175°C; Reverse Recovery Time Trr Max:150Ns; Termination Type:Screw; Voltage Vds Typ:100V; Voltage Vgs Max:20V; Voltage Vgs Rds On Measurement:10V
