B72220S0151K101 - Varistor, 85.0J, 150Vac

Varistor, 85.0J, 150Vac; Voltage Rating Vac:150V; Voltage Rating V Dc:200V; Product Range:B722 Series; Clamping Voltage Vc Max:395V; Varistor Case Style:Disc 20Mm; Varistor Type:Metal Oxide Varistor (Mov); Peak Surge Current @ 8/20Μs:6.5Ka; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Peak Energy (10/1000Us):85J; Automotive Qualification Standard:-; Svhc:No Svhc (27-Jun-2018); Approval Bodies:Cecc, Csa, Ul; Body Diameter:22.5Mm; Capacitance:1160Pf; Clamping Voltage @ 8/20Μs Max:395V; External Depth:1Mm; External Length / Height:26Mm; Lead Length:30Mm; Peak Pulse Current Ipp @ 8/20Μs:8000A; Suppressor Type:Varistor; Surge Current:8Ka; Transient Energy:85J; Varistor Voltage:240V; Varistor Voltage @ 1Ma:216V; Varistor Voltage @ 1Ma Max:264V; Varistor Voltage Tolerance +:10%
