NMXS1212UC - Converter, Dc/Dc, 5W, 12V

Converter, Dc/Dc, 5W, 12V; No. Of Outputs:1 Output; Output Power Max:5W; Output Voltage - Output 1:12V; Output Current - Output 1:417Ma; Output Voltage - Output 2:-; Output Current - Output 2:-; Output Voltage - Output 3:-; Output Current - Output 3:-; Product Range:Nmxu Series; Input Voltage Dc Min:10.8V; Input Voltage Dc Max:13.2V; Dc / Dc Converter Output Type:Fixed; Dc / Dc Converter Type:Dip; Dc / Dc Converter Mounting:Through Hole; Width:23.5Mm; Height:10Mm; Depth:25.03Mm; Svhc:No Svhc (07-Jul-2017); Efficiency:85%; External Depth:10Mm; External Length / Height:20.32Mm; External Width:25Mm; Flammability Rating:Ul94v-0; Input Voltage:12Vdc; Input Voltage Tolerance +:10%; Isolation Voltage:1Kv; Line Regulation:1.1%; Load Regulation:5%; No. Of Outputs:1Outputs; Operating Temperature Max:70°C; Operating Temperature Min:-25°C; Output Ripple Voltage Pk-Pk:125Mv; Output Voltage Tolerance +:5%; Output Voltage Tolerance -:2.5%; Pin Diameter:1.02Mm; Power Density:0.85W/Cm³; Power Rating:5W
