    TEN 5-4821WI - Converter, Dc/Dc, 6W, +/-5V/0.5A

    Manufacturer: Tracopower
    Order Code: 1007482
    Manufacturer part number: TEN 5-4821WI
    Technical Datasheet: TEN 5-4821WI Datasheet
    Availability: Out of stock
    Legislation and Environmental
    Country of Origin: TW
    RoHS Compliant: Y10
    SVHC: 0
    Weight (KG): 0.0140
    Tariff No: 85044090
    0.0 0
    Write your own review Close
    *
    *
    • Bad
    • Excellent
    *
    *
    *
    *
    Converter, Dc/Dc, 6W, +/-5V/0.5A; No. Of Outputs:2 Output; Output Power Max:5W; Output Voltage - Output 1:5V; Output Current - Output 1:500Ma; Output Voltage - Output 2:-5V; Output Current - Output 2:500Ma; Output Voltage - Output 3:-; Output Current - Output 3:-; Product Range:Ten 5Wi Series; Input Voltage Dc Min:18V; Input Voltage Dc Max:75V; Dc / Dc Converter Output Type:Fixed; Dc / Dc Converter Type:Dip; Dc / Dc Converter Mounting:Through Hole; Width:20.3Mm; Height:10.2Mm; Depth:31.8Mm; Svhc:No Svhc (27-Jun-2018); Approval Bodies:En 60950, Iec 60950, Ul/Cul 60950; Approvals & Standards:Iec, Ul; Efficiency:79%; Isolation Voltage:1.5Kv; No. Of Outputs:2Outputs; Output Current - Max:500Ma; Output Voltage +:5Vdc; Output Voltage -:5Vdc; Power Rating:5W; Supply Voltage:48V
